A red Chevrolet Corvette parked nose-out in a working shop bay, a wall of tools and bottles behind it, wheels stacked overhead and daylight through the open bay door.

PPF for install shops: Carry ARK in your shop.

ARK is a paint protection film (PPF) brand started in Canada, and a film supplier to install shops: rolls for your own plotter, and pre-cut kits. Join the authorized dealers who install the film around the world, with the warranty behind you. Four things first, so you have them before you read anything else.

We sell direct
We also sell to car owners: pre-cut kits, film by the yard and full rolls. Most of what we sell is rolls to professional install shops, and we’d rather you heard the rest from us.
No favourites
We name no dealer on this site, so none is featured over another. A car owner who asks us is matched to an authorized dealer by a person, not by a directory.
Cutting
No in-house cutting software. Most shops buy rolls and cut them on their own plotter and software; pre-cut kits are available too. The cut spec is published here as it is measured.
Where you can sell
Nothing in writing on where you can sell, and we’d rather say so.

What you get, and what you don’t.

A dark shop floor with a classic Porsche 911 and a Porsche SUV parked under two large warm ceiling light panels, their reflections stretching across the polished concrete.

Made for

Cars first. Aircraft and boats too. Built for extreme weather conditions.

Warranty backing

10 years on every film. A covered claim pays for replacement film, and the labour to take off the failed film and fit the new one, and the warranty moves with the car when it is sold. The terms your customers get.

Certified

It means one thing: a shop is authorised to install ARK, with warranty backing.

Who built it

A group of engineers who worked with leading paint protection film companies.

Built against the call-backs every installer knows: adhesive that fails, stretch marks, poor clarity and yellowing over time.

In the box

The roll label.

The Defender label prints thickness, finish, warranty, lot and date, so a roll traces back to its batch when a claim comes in. The standard roll is 60 in × 50 ft. Reading a PPF data sheet.

Your plotter, our numbers.

No in-house cutting software. Most shops buy rolls and cut them on their own plotter and software; pre-cut kits are available too. The cut spec is published here as it is measured. These are starting settings. Blades and plotters differ, so confirm them with a test cut on an offcut before a full job: Cutting PPF rolls on your own plotter and software.

Cut spec

Backing thickness
3 mil (75 µm) PET liner
Blade depth
45° blade, through film and adhesive, scoring the liner only
Offset
0.25 mm
Platform
Bring your own platform

Three rungs. The bar for each is being written.

The rungs are named. What it takes to reach each one, and what changes when you do, is not written down yet, so it shows as pending rather than as a number that sounds right.

  • Authorized

    ⟨ threshold pending ⟩

    What changes at this rung: ⟨ pending ⟩

  • Elite

    ⟨ threshold pending ⟩

    What changes at this rung: ⟨ pending ⟩

  • Master

    ⟨ threshold pending ⟩

    What changes at this rung: ⟨ pending ⟩

A margin calculator for PPF jobs.

Your numbers, not ours. We do not publish a margin, and we do not print our roll price on this site. Put in what the job pays you, what the film costs you, the hours in the bay and what an hour costs you. Your margin is the charge, less the film, less the hours times the hourly cost.

Before tax.

Including waste.

Prep, install and inspection.

Wages and bay time.

Your margin on the job

Fill in all four and it shows here. Nothing you type leaves this page.

Before you apply.

The questions a shop asks about carrying a film brand, answered short. The application is below.

ARK’s authorized dealers are the install shops that carry its film. An ARK certificate says a shop is authorised to install ARK, with warranty backing. Every ARK film carries the same warranty: 10 years, labour included on a covered claim, and it transfers to the car’s next owner.

Apply through the installer page.

  1. Send the application with your shop’s details and the work it does.
  2. A person reads it, and answers within one business day, with questions about your shop.

The standard roll is 60 in × 50 ft, the size ARK supplies to shops and prints on its roll label. Defender and Fusion are 8.5 mil thick; Umbra (a working name) and Spectrum are 8 mil.

The long answer: Cutting PPF rolls on your own plotter and software

It names the production batch the roll came from. On an ARK roll label, the lot number and the “mfg” date give the batch and the month the roll was made, so a roll traces back to its batch. Note it on the job record and keep it with the invoice, so a claim can be traced to the roll it came from.

Judge it on what it puts in writing. Ask for:

  • A data sheet for every film
  • The warranty term, and whether a claim pays your labour too
  • Whether the warranty transfers to the car’s next owner
  • Rolls for your own plotter, pre-cut kits, or both
  • Who makes the film, and how fast a person replies

No. The ARK site names no dealer, in any list, credit or map, so no shop is featured over another. When a car owner asks ARK for an installer, a person matches the car to an authorized dealer instead of sending the owner to a directory.

Apply to carry ARK.

Tell us about your shop. A person reads every application.

A person reads it, and answers within one business day.

Optional. Email is how we reply.

So we know where your shop is.

Brands you already install, if any.
